Balun for dipole 1:1 (DB11K)

90.00 70.00

Balun for dipole 1:1. Model DB11K. 1-54 MHZ


Balun for dipole 1:1
Model DB11K

Freq. 1-54 MHZ
Power – 1kw (1.5kw peak)
DIGI – 500w (1kw peak)
Insertion Loss Less than 0.02db
Choke more than -30db

Amidon core FT240-K (K material is used primarily in transmission line transformers from 1 MHz to 50 MHz. AL Value: 458)
Silverplated wire 1.5mm
Polycarbonate box ip65
Other stuff – copper, brass, stainless steel

if you do not find the balun you need, or power rate to small and you need “biggunbalun”- contact me

All my balun it custom handmade.
For more info about payment and shipping please contact –
In Ukraine I cant receive by PayPal. I can receive money only with
Shipping to US via EMS company 7-14 days
Other countries by regular post service 14-24 days

Additional information

Weight 0.6 kg
